DSE124 CANbus Extender with Fibre Optic #0124-01
$ 99.23
Deep Sea Electronics DSE124 CANbus Extender For Sale The DSE124 CANbus extender has been designed to extend a multi-set comms load share link or engine CANbus. Order your DSE124 expansion module today from Power Systems Plus in Oregon! OVERALL SIZE 134 mm x 77 mm x 49 mm (5.3” x 3.0” x 1.9”) WEIGHT 0.2kg Key Features and Benefits: DIN rail & chassis mount. Provides multiple installation options. Two variants – Fibre optic/non fibre optic. Suitable for a wide number of different applications. Four red indicator LEDs. Provides full monitoring flexibility. Max 8 copper 250m segments and 2 fibre optic 2000m segments can be used simultaneously. Provides multiple installation options. DC SUPPLY MINIMUM SUPPLY VOLTAGE 8 V continuous CRANKING DROPOUTS Able to survive 0V for 50mS providing the supply was at least 10V before the dropout and recovers to 5 volts afterwards. MAX OPERATING SUPPLY VOLTAGE 35V continuous. MAX OPERATING SUPPLY CURRENT 191mA at 12V, 99mA at 24V. Digital input grounded, passing MSC protocol at 75% bus capacity, Fibre port fitted. MAXIMUM STANDBY CURRENT 147mA at 12V, 76mA at 24V digital input open circuit, no activity on CAN or Fibre ports. DIGITAL INPUT 1 x configurable digital input
