DSE2130 DSENet Input Expansion Module
$ 99.37
DSE2130 DSENet Input Expansion Module For Sale This item has a 3-4 week lead time from receipt of order! Deep Sea Electronics DSE2130 DSENet Input Expansion Module DSE 2130 The DSE2130 is an input expansion module providing 8 additional inputs to the control module. Four of these can be configured for use as analogue inputs. Up to 4 x DSE2130 modules can be linked together to provide up to 32 additional inputs. Designed to give greater flexibility for meeting complex industry generator control specifications. All configurations are controlled within the host control module. DC SUPPLY CONTINUOUS VOLTAGE RATING 8 V to 35 V Continuous CRANKING DROPOUTS Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking. MAXIMUM OPERATING CURRENT200 mA at 12 V, 100 mA at 24 VMAXIMUM STANDBY CURRENT120 mA at 12 V, 60 mA at 24 V
