GV121CAX, Contactor SPST-NO, 200 AMP, 12-100VDC, 24VDC Coil, 38cm Flying leads, IP67
$ 62.09
Gigavac GV121CAX, Contactor SPST-NO, 200 AMP, 12-100VDC, 24VDC Coil, 38cm Flying leads, IP67, SIDE MOUNTINGFeaturesHermetically SealedUL1604 for Class I & II Div 2 and Class III for use in hazardous locationsIP67 – Temporary water immersion (30 Min)SAE J1171 External ignition protectionISO8846 Protection against ignition around flammable gassesCE ApprovedHigh Efficiency Dual DC Coils – Very low 12,24,48VDC continuous coil power with no EMI emissions or cross-talk on your system control powerIdeal for battery powered systems or where low power is neededPWM option provides additional drive control flexibilityBuilt in Coils suppression for all DC CoilsFlexible package for installationSpecificationGigavac Part NumberGV121CAXMain Contact TypeSPST-NOAuxiliary Contact TypeNoneCoil Voltage24VDCLoad Current 200 AmpMechanical Life @ 0 Amp1,000,000 OperationsDielectric at Sea Level (leakage <1mA)2.5kV rmsControl Input Terminals38cm Flying LeadsSpecial FeatureNoneMounting StylePanel Mount (M5)Load Voltage Range12 – 100VDCStandardsCE, UL1604, IP67, SAEJ1171Termination StyleM8Unit Weight450gFactory Pack Qty1Datasheet
